Outer Prop Welding Machine

Outer Prop Welding Machine

Product Details

Drive A.C. Motor with V.F.D
R.P.M. 2 to 12
Motor 0.5 H.P., 1440 R.P.M.
Operation Automatic
Air Pressure Required 4 to 5 Bar
Length Adjustment 500 to 3000mm
Supply 1 Phase, 220 Volts ±5%, 3 Phase, 415 Volts ±5%
Power 1 K.V.A., 9x2=18 K.V.A. Max.
Frequency 50/60 H.Z.
Operating Voltage Operating Voltage
Control PLC with Touch Screen/Digital
Production 400-450 Approx.
Dimensions 14(L) x 2.5(W) x 5.3(H) Feet Approx.
Weight 800 Kgs.(Approx.)

Features: High production, easy to operate, easy to maintain, uniform welding results, Inbuilt Mig Welding, Bearings from Taiwan, Janatics Pneumatics .

Description: Automatic outer prop welding machine is used to weld base plate with pipe and sleeve without making any joint between them, it gives high production and accuracy to product. Outer prop are used with combination of inner prop and base jack to make a sctructure. All the components are used in combination of each other base jack welding machine, inner prop welding machine, outer prop welding machine, cuplock welding machine, ringlock welding machine.
