Hydraulic Pipe Threading Machine


Hydraulic Pipe Threading Machine

We are a renowned Manufacturer, Supplier, and Exporter of Hydraulic Pipe Threading Machine, operating from Ludhiana, Punjab. Hydraulic Pipe Threading Machine is designed for efficient and fast production of thread onto pipes and fittings. Hydraulic Pipe Threading Machine is useful for minimizing Exterior Line on Pipe joints by Pursuing Method. HSS Tangential Chasers are used as blades. Matric, BSP, BSPT, NPT, UNF, UNC, BSW, Acme Discussions B.S.F etc. threads can be done onto pipes. Hydraulic Pipe Threading Machine is fitted with sturdy gears that are made of case hardened steel with extra-large face with, tooth thickness, and cut on hobbing machine for noiseless operation even at high speed.

Design & Workmanship : Hydraulic Pipe Threading Machine is designed to produce precise threads within the tolerance for which they were intended.

Head Stock : A heavy duty geared Head Box is of best quality casting providing support to the spindle bearings. The box is of gear type, lubricated, and fitted with three extra heavy-duty bearings.

The Bed : The bed is pillar type having two pillars made of best quality steel nicely finished & duly hard chrome plated in the most modern hard chrome-plating unit.

The Saddle : The Saddle is fitted on two pillars very precisely. It runs on pillars very smoothly and accurately to the Head Stock alignment.

The Apron : The apron gives movement to the saddle with head transfer along with pillars through steel rack and pinion arrangements. All the gears are made of best quality steel.

Vice Jaws : The vice jaws made from the best quality alloy steel are fitted on the saddle well aligned with the head stock center fitted in a heavy-duty box type vice. The jaws are heat-treated. The movements of jaws are controlled by a screw on the saddle.

Range of NCT Threading Machines and Die Heads
  • 1/2" to 2.1/2" do/-
  • 1" to 4" Capacity Pipe
  • 2.1/2" to 6" Capacity Pipe
  • 4" to 8" 4" to 8" Capacity Pipe


Technical Specifications

 Model NCT-2.1/2"  1/2" to 2.1/2" (Pillar Type)
 Saddle Movement  12"-16"
 Spindle Speed Range  60-90-120
 Number of Spindle Speed 3
 Threading Capacity  1/2" to 2.1/2"
 Production per Hour  70-90
 H.P. Required  7.5 H.P. 960 RPM
 Lead Screw  As Per Requirement
 Weight (KG) 990





 Model NCT-4"  1" to 4" (Pillar Type)
 Saddle Movement  10"-12"
 Spindle Speed Range  40-75-115
 Number of Spindle Speed 3
 Threading Capacity  1" to 4"
 Production per Hour  35-40
 H.P. Required  12.5 H.P. 960 RPM
 Lead Screw  Provided
 Weight (KG) 1600





 Model NCT-6"  2.1/2" to 6" (Pillar Type)
 Saddle Movement  10"-12"
 Spindle Speed Range  25-50
 Number of Spindle Speed 2
 Threading Capacity  2.1/2" to 6"
 Production per Hour  20-25
 H.P. Required  15 H.P. 960 RPM
 Lead Screw  Provided
 Weight (KG) 1900





 Model NCT-8"  4" to 8" (Pillar Type)
 Saddle Movement  10"-12"
 Spindle Speed Range  25-50
 Number of Spindle Speed 2
 Threading Capacity  4" to 8"
 Production per Hour  15-20
 H.P. Required  20 H.P. 960 RPM
 Lead Screw  Provided
 Weight (KG) 2500
